1-87022-1
TE Connectivity AMP Connectors- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN PC PIN SQUARE 0.025 GOLD
- CategoryTerminals - PC Pin, Single Post Connectors
- Datasheet 1-87022-1 Datasheet
-
ECAD Model
- Share
In Stock: 139
Can ship immediately
Pricing:
- 1$0.44435
- 120,000$0.34463
Quote It
Technical Details
- Series:AMPMODU Mod II
- Package:Reel
- Part Status:Active
- Terminal Type:Single Post
- Terminal Style:Smooth
- Pin Size - Above Flange:0.025" (0.64mm) Square
- Pin Size - Below Flange:0.025" (0.64mm) Square
- Length - Above Flange:-
- Length - Below Flange:-
- Length - Overall:0.443" (11.25mm)
- Flange Diameter:-
- Mounting Hole Diameter:0.036" (0.91mm)
- Mounting Type:Through Hole
- Termination:Press-Fit
- Insulation:Non-Insulated
- Board Thickness:-
- Contact Material:Phosphor Bronze
- Contact Finish:Gold
- Contact Finish Thickness:50.0µin (1.27µm)
