2N5060RLRMG
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSCR 30V 800MA TO92-3
- CategoryThyristors - SCRs
- Datasheet 2N5060RLRMG Datasheet
-
ECAD Model
- Share
In Stock: 151
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Obsolete
- Voltage - Off State:30 V
- Voltage - Gate Trigger (Vgt) (Max):800 mV
- Current - Gate Trigger (Igt) (Max):200 µA
- Voltage - On State (Vtm) (Max):1.7 V
- Current - On State (It (AV)) (Max):510 mA
- Current - On State (It (RMS)) (Max):800 mA
- Current - Hold (Ih) (Max):5 mA
- Current - Off State (Max):10 µA
- Current - Non Rep. Surge 50, 60Hz (Itsm):10A @ 60Hz
- SCR Type:Sensitive Gate
- Operating Temperature:-40°C ~ 110°C
- Mounting Type:Through Hole
- Package / Case:TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
- Supplier Device Package:TO-92-3
