TS420-700T
STMicroelectronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSCR 700V 4A TO220AB
- CategoryThyristors - SCRs
- Datasheet TS420-700T Datasheet
-
ECAD Model
- Share
In Stock: 104
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- Voltage - Off State:700 V
- Voltage - Gate Trigger (Vgt) (Max):800 mV
- Current - Gate Trigger (Igt) (Max):200 µA
- Voltage - On State (Vtm) (Max):1.6 V
- Current - On State (It (AV)) (Max):2.5 A
- Current - On State (It (RMS)) (Max):4 A
- Current - Hold (Ih) (Max):5 mA
- Current - Off State (Max):5 µA
- Current - Non Rep. Surge 50, 60Hz (Itsm):30A, 33A
- SCR Type:Sensitive Gate
- Operating Temperature:-40°C ~ 125°C
- Mounting Type:Through Hole
- Package / Case:TO-220-3
- Supplier Device Package:TO-220AB
