SN74LVC823APWT
Texas Instruments
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC FF D-TYPE SNGL 9BIT 24TSSOP
- CategoryLogic - Flip Flops
-
ECAD Model
- Share
In Stock: 1,172
Can ship immediately
Pricing:
- 1$1.16
- 1,000$0.4995
Quote It
Technical Details
- Series:74LVC
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Function:Master Reset
- Type:D-Type
- Output Type:Tri-State, Non-Inverted
- Number of Elements:1
- Number of Bits per Element:9
- Clock Frequency:150 MHz
- Max Propagation Delay @ V, Max CL:8ns @ 3.3V, 50pF
- Trigger Type:Positive Edge
- Current - Output High, Low:24mA, 24mA
- Voltage - Supply:1.65V ~ 3.6V
- Current - Quiescent (Iq):10 µA
- Input Capacitance:5 pF
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Supplier Device Package:24-TSSOP
- Package / Case:24-TSSOP (0.173", 4.40mm Width)
