M74HC76B1R

Technical Details

• Series:74HC
• Package:Tube
• Part Status:Obsolete
• Function:Set(Preset) and Reset
• Type:JK Type
• Output Type:Complimentary
• Number of Elements:2
• Number of Bits per Element:1
• Clock Frequency:67 MHz
• Max Propagation Delay @ V, Max CL:21ns @ 6V, 50pF

• Trigger Type:Negative Edge
• Current - Output High, Low:5.2mA, 5.2mA
• Voltage - Supply:2V ~ 6V
• Current - Quiescent (Iq):2 µA
• Input Capacitance:5 pF
• Operating Temperature:-55°C ~ 125°C (TA)
• Mounting Type:Through Hole
• Supplier Device Package:16-DIP
• Package / Case:16-DIP (0.300", 7.62mm)
