ACNU-250L-500E
Broadcom
- Lifecycle status Active
- RoHS RoHS Compliant
- Description11MM OPTOCOUPLER (1MBD)
- CategoryOptoisolators - Transistor, Photovoltaic Output
-
ECAD Model
- Share
In Stock: 186
Can ship immediately
Pricing:
- 1$1.78398
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Active
- Number of Channels:1
- Voltage - Isolation:5000Vrms
- Current Transfer Ratio (Min):23% @ 12mA
- Current Transfer Ratio (Max):53% @ 12mA
- Turn On / Turn Off Time (Typ):700ns, 400ns
- Rise / Fall Time (Typ):-
- Input Type:DC
- Output Type:Transistor
- Voltage - Output (Max):24V
- Current - Output / Channel:12mA
- Voltage - Forward (Vf) (Typ):1.5V
- Current - DC Forward (If) (Max):-
- Vce Saturation (Max):-
- Operating Temperature:-40°C ~ 105°C
- Mounting Type:Surface Mount
- Package / Case:8-SOIC (0.378", 9.60mm Width)
- Supplier Device Package:8-SO Stretched
