SN74HC258PW
Texas Instruments
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC MULTIPLEXER 4 X 2:1 16TSSOP
- CategoryLogic - Signal Switches, Multiplexers, Decoders
-
ECAD Model
- Share
In Stock: 1,841
Can ship immediately
Pricing:
- 1$0.6
- 1,710$0.256
Quote It
Technical Details
- Series:74HC
- Package:Tube
- Part Status:Active
- Type:Multiplexer
- Circuit:4 x 2:1
- Independent Circuits:1
- Current - Output High, Low:7.8mA, 7.8mA
- Voltage Supply Source:Single Supply
- Voltage - Supply:2V ~ 6V
- Operating Temperature:-40°C ~ 85°C
- Mounting Type:Surface Mount
- Package / Case:16-TSSOP (0.173", 4.40mm Width)
- Supplier Device Package:16-TSSOP
