DG409DJ
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDUAL 4-CHANNEL CMOS ANALOG MUX
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet DG409DJ Datasheet
-
ECAD Model
- Share
In Stock: 2,025
Can ship immediately
Pricing:
- 1$2.27
- 500$2.27
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- Switch Circuit:SP4T
- Multiplexer/Demultiplexer Circuit:4:1
- Number of Circuits:2
- On-State Resistance (Max):100Ohm
- Channel-to-Channel Matching (ΔRon):15Ohm (Max)
- Voltage - Supply, Single (V+):5V ~ 34V, ±5V ~ 20V
- Voltage - Supply, Dual (V±):5V ~ 34V, ±5V ~ 20V
- Switch Time (Ton, Toff) (Max):150ns, 150ns
- -3db Bandwidth:-
- Charge Injection:20pC
- Channel Capacitance (CS(off), CD(off)):3pF, 14pF
- Current - Leakage (IS(off)) (Max):500pA
- Crosstalk:-
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Through Hole
- Package / Case:16-DIP (0.300", 7.62mm)
- Supplier Device Package:16-PDIP
