MAX4665CSE
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionQUAD,SPST ANALOG SWITCH
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet MAX4665CSE Datasheet
-
ECAD Model
- Share
In Stock: 748
Can ship immediately
Pricing:
- 1$4.04
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- Switch Circuit:SPST - NO
- Multiplexer/Demultiplexer Circuit:1:1
- Number of Circuits:4
- On-State Resistance (Max):4Ohm
- Channel-to-Channel Matching (ΔRon):200mOhm
- Voltage - Supply, Single (V+):4.5V ~ 36V
- Voltage - Supply, Dual (V±):±4.5V ~ 20V
- Switch Time (Ton, Toff) (Max):275ns, 175ns
- -3db Bandwidth:-
- Charge Injection:300pC
- Channel Capacitance (CS(off), CD(off)):34pF, 34pF
- Current - Leakage (IS(off)) (Max):500pA
- Crosstalk:-60dB @ 1MHz
- Operating Temperature:0°C ~ 70°C (TA)
- Mounting Type:Surface Mount
- Package / Case:16-SOIC (0.154", 3.90mm Width)
- Supplier Device Package:16-SOIC
