MUX509IPW

Technical Details

• Series:-
• Package:Tube
• Part Status:Active
• Switch Circuit:SP4T
• Multiplexer/Demultiplexer Circuit:4:1
• Number of Circuits:2
• On-State Resistance (Max):170Ohm
• Channel-to-Channel Matching (ΔRon):2.4Ohm
• Voltage - Supply, Single (V+):10V ~ 36V
• Voltage - Supply, Dual (V±):±5V ~ 18V

• Switch Time (Ton, Toff) (Max):136ns, 75ns
• -3db Bandwidth:-
• Charge Injection:0.3pC
• Channel Capacitance (CS(off), CD(off)):2.4pF, 4.3pF
• Current - Leakage (IS(off)) (Max):1nA
• Crosstalk:-96dB @ 1MHz
• Operating Temperature:-40°C ~ 125°C (TA)
• Mounting Type:Surface Mount
• Package / Case:16-TSSOP (0.173", 4.40mm Width)
• Supplier Device Package:16-TSSOP
