DG406DN+T
Maxim Integrated
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC MULTIPLEXER 16X1 28PLCC
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet DG406DN+T Datasheet
-
ECAD Model
- Share
In Stock: 5,175
Can ship immediately
Pricing:
- 1$9.152
- 500$8.06481
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Active
- Switch Circuit:-
- Multiplexer/Demultiplexer Circuit:16:1
- Number of Circuits:1
- On-State Resistance (Max):100Ohm
- Channel-to-Channel Matching (ΔRon):1.5Ohm
- Voltage - Supply, Single (V+):5V ~ 30V
- Voltage - Supply, Dual (V±):±4.5V ~ 20V
- Switch Time (Ton, Toff) (Max):200ns, 150ns
- -3db Bandwidth:-
- Charge Injection:2pC
- Channel Capacitance (CS(off), CD(off)):8pF, 130pF
- Current - Leakage (IS(off)) (Max):500pA
- Crosstalk:-92dB @ 100kHz
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Package / Case:28-LCC (J-Lead)
- Supplier Device Package:28-PLCC (11.51x11.51)
