TS5A3359DCURG4

Technical Details

• Series:-
• Package:Tape & Reel (TR)
• Part Status:Obsolete
• Switch Circuit:SP3T
• Multiplexer/Demultiplexer Circuit:3:1
• Number of Circuits:1
• On-State Resistance (Max):900mOhm
• Channel-to-Channel Matching (ΔRon):100mOhm
• Voltage - Supply, Single (V+):1.65V ~ 5.5V
• Voltage - Supply, Dual (V±):-

• Switch Time (Ton, Toff) (Max):21ns, 10.5ns
• -3db Bandwidth:75MHz
• Charge Injection:20pC
• Channel Capacitance (CS(off), CD(off)):18pF, 54pF
• Current - Leakage (IS(off)) (Max):20nA
• Crosstalk:-64dB @ 1MHz
• Operating Temperature:-40°C ~ 85°C (TA)
• Mounting Type:Surface Mount
• Package / Case:8-VFSOP (0.091", 2.30mm Width)
• Supplier Device Package:8-VSSOP
