10564CS
Century Spring Corp.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCOMP O= .609,L= 2.03,W= .052
- CategorySprings - Compression, Tapered
-
ECAD Model
- Share
In Stock: 470
Can ship immediately
Pricing:
- 1$3.24
Quote It
Technical Details
- Series:-
- Package:Box
- Part Status:Active
- Material:Spring Steel
- Wire Diameter:0.052" (1.32mm)
- Diameter - Outside:0.609" (15.47mm)
- Diameter - Inside:0.505" (12.83mm)
- Diameter - Small Outside:-
- Diameter - Large Outside:-
- Free Length:2.030" (51.56mm)
- Max Load:-
- Rate:6.2 lbs/in
- End Style:Closed & Ground
- Finish:Zinc
