TA-2276CS
Century Spring Corp.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionLO= 0.938, SO= 0.625, W= 0.035
- CategorySprings - Compression, Tapered
-
ECAD Model
- Share
In Stock: 874
Can ship immediately
Pricing:
- 1$3.26
Quote It
Technical Details
- Series:-
- Package:Box
- Part Status:Active
- Material:Stainless Steel
- Wire Diameter:0.035" (0.89mm)
- Diameter - Outside:-
- Diameter - Inside:0.560" (14.22mm)
- Diameter - Small Outside:0.625" (15.88mm)
- Diameter - Large Outside:0.938" (23.83mm)
- Free Length:0.940" (23.88mm)
- Max Load:-
- Rate:2.0 lbs/in
- End Style:Closed
- Finish:None
