TA-2305CS
Century Spring Corp.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionLO= 0.688, SO= 0.562, W= 0.08
- CategorySprings - Compression, Tapered
-
ECAD Model
- Share
In Stock: 2,947
Can ship immediately
Pricing:
- 1$3.55
Quote It
Technical Details
- Series:-
- Package:Box
- Part Status:Active
- Material:Spring Steel
- Wire Diameter:0.080" (2.03mm)
- Diameter - Outside:-
- Diameter - Inside:0.400" (10.16mm)
- Diameter - Small Outside:0.562" (14.27mm)
- Diameter - Large Outside:0.688" (17.48mm)
- Free Length:1.500" (38.10mm)
- Max Load:-
- Rate:60.6 lbs/in
- End Style:Closed
- Finish:None
