G-46CS
Century Spring Corp.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCOMP O= .546,L= 1.75,W= .041
- CategorySprings - Compression, Tapered
-
ECAD Model
- Share
In Stock: 1,595
Can ship immediately
Pricing:
- 1$3.6
Quote It
Technical Details
- Series:-
- Package:Box
- Part Status:Active
- Material:Stainless Steel
- Wire Diameter:0.041" (1.04mm)
- Diameter - Outside:0.546" (13.87mm)
- Diameter - Inside:0.464" (11.79mm)
- Diameter - Small Outside:-
- Diameter - Large Outside:-
- Free Length:1.750" (44.45mm)
- Max Load:-
- Rate:1.6 lbs/in
- End Style:Closed
- Finish:None
