10935CS
Century Spring Corp.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCOMP O= .859,L= 2.84,W= .041
- CategorySprings - Compression, Tapered
-
ECAD Model
- Share
In Stock: 1,020
Can ship immediately
Pricing:
- 1$3.68
Quote It
Technical Details
- Series:-
- Package:Box
- Part Status:Active
- Material:Spring Steel
- Wire Diameter:0.041" (1.04mm)
- Diameter - Outside:0.859" (21.82mm)
- Diameter - Inside:0.777" (19.74mm)
- Diameter - Small Outside:-
- Diameter - Large Outside:-
- Free Length:2.840" (72.14mm)
- Max Load:-
- Rate:0.93 lbs/in
- End Style:Closed
- Finish:None
