3390CS
Century Spring Corp.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCOMP O=1.015,L= 1.50,W= .095
- CategorySprings - Compression, Tapered
-
ECAD Model
- Share
In Stock: 1,815
Can ship immediately
Pricing:
- 1$4.18
Quote It
Technical Details
- Series:-
- Package:Box
- Part Status:Active
- Material:Spring Steel
- Wire Diameter:0.095" (2.41mm)
- Diameter - Outside:1.015" (25.78mm)
- Diameter - Inside:0.825" (20.96mm)
- Diameter - Small Outside:-
- Diameter - Large Outside:-
- Free Length:1.500" (38.10mm)
- Max Load:-
- Rate:30.0 lbs/in
- End Style:Closed & Ground
- Finish:Zinc
