B17-153CS
Century Spring Corp.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCOMP O=1.250,L= 1.75,W= .043
- CategorySprings - Compression, Tapered
-
ECAD Model
- Share
In Stock: 1,063
Can ship immediately
Pricing:
- 1$5.1
Quote It
Technical Details
- Series:-
- Package:Box
- Part Status:Active
- Material:Stainless Steel
- Wire Diameter:0.043" (1.09mm)
- Diameter - Outside:1.250" (31.75mm)
- Diameter - Inside:1.164" (29.57mm)
- Diameter - Small Outside:-
- Diameter - Large Outside:-
- Free Length:1.750" (44.45mm)
- Max Load:-
- Rate:0.13 lbs/in
- End Style:Closed
- Finish:None
