71652SCS
Century Spring Corp.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCOMP O= .540,L= 1.25,W= .046
- CategorySprings - Compression, Tapered
-
ECAD Model
- Share
In Stock: 8,095
Can ship immediately
Pricing:
- 1$7.04
Quote It
Technical Details
- Series:-
- Package:Box
- Part Status:Active
- Material:Stainless Steel
- Wire Diameter:0.046" (1.17mm)
- Diameter - Outside:0.540" (13.72mm)
- Diameter - Inside:0.448" (11.38mm)
- Diameter - Small Outside:-
- Diameter - Large Outside:-
- Free Length:1.250" (31.75mm)
- Max Load:-
- Rate:9.4 lbs/in
- End Style:Closed & Ground
- Finish:None
