72505CS
Century Spring Corp.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCOMP O=1.100,L= 1.00,W= .082
- CategorySprings - Compression, Tapered
-
ECAD Model
- Share
In Stock: 341
Can ship immediately
Pricing:
- 1$10.2
Quote It
Technical Details
- Series:-
- Package:Box
- Part Status:Active
- Material:Music Wire
- Wire Diameter:0.082" (2.08mm)
- Diameter - Outside:1.100" (27.94mm)
- Diameter - Inside:0.936" (23.77mm)
- Diameter - Small Outside:-
- Diameter - Large Outside:-
- Free Length:1.000" (25.40mm)
- Max Load:-
- Rate:36.0 lbs/in
- End Style:Closed & Ground
- Finish:None
