MAX506AEWP+
Maxim Integrated
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC DAC 8BIT V-OUT 20SOIC
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet MAX506AEWP+ Datasheet
-
ECAD Model
- Share
In Stock: 361,471
Can ship immediately
Pricing:
- 1$17.03
- 10$15.70436
- 36$15.12479
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Number of Bits:8
- Number of D/A Converters:4
- Settling Time:6µs (Typ)
- Output Type:Voltage - Buffered
- Differential Output:No
- Data Interface:Parallel
- Reference Type:External
- Voltage - Supply, Analog:±5V
- Voltage - Supply, Digital:5V
- INL/DNL (LSB):-, ±1 (Max)
- Architecture:R-2R
- Operating Temperature:-40°C ~ 85°C
- Package / Case:20-SOIC (0.295", 7.50mm Width)
- Supplier Device Package:20-SOIC
- Mounting Type:Surface Mount
