- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC DAC 8BIT V-OUT 16CDIP
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet AD558TD Datasheet
-
ECAD Model
- Share
In Stock: 112
Can ship immediately
Pricing:
- 1$73.45
- 23$69.00282
- 46$66.77709
Quote It
Technical Details
- Series:DACPORT®
- Package:Tube
- Part Status:Active
- Number of Bits:8
- Number of D/A Converters:1
- Settling Time:3µs
- Output Type:Voltage - Buffered
- Differential Output:No
- Data Interface:Parallel
- Reference Type:Internal
- Voltage - Supply, Analog:4.5V ~ 16.5V
- Voltage - Supply, Digital:4.5V ~ 16.5V
- INL/DNL (LSB):±0.375 (Max), -
- Architecture:R-2R
- Operating Temperature:-55°C ~ 125°C
- Package / Case:16-CDIP (0.300", 7.62mm)
- Supplier Device Package:16-CDIP
- Mounting Type:Through Hole
