AD7224LNZ
Linear Technology (Analog Devices, Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC DAC 8BIT V-OUT 18DIP
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet AD7224LNZ Datasheet
-
ECAD Model
- Share
In Stock: 205
Can ship immediately
Pricing:
- 1$25.37
- 20$23.39419
- 100$19.97679
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Number of Bits:8
- Number of D/A Converters:1
- Settling Time:20µs
- Output Type:Voltage - Buffered
- Differential Output:No
- Data Interface:Parallel
- Reference Type:External
- Voltage - Supply, Analog:11.4V ~ 16.5V, ±5V
- Voltage - Supply, Digital:14.25V ~ 15.75V
- INL/DNL (LSB):±0.5 (Max), ±1 (Max)
- Architecture:R-2R
- Operating Temperature:-40°C ~ 85°C
- Package / Case:18-DIP (0.300", 7.62mm)
- Supplier Device Package:18-PDIP
- Mounting Type:Through Hole
