AD5422ACPZ-REEL7
Linear Technology (Analog Devices, Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC DAC 16BIT V OR A-OUT 40LFCSP
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet AD5422ACPZ-REEL7 Datasheet
-
ECAD Model
- Share
In Stock: 177
Can ship immediately
Pricing:
- 1$12.93
- 750$9.01788
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Number of Bits:16
- Number of D/A Converters:1
- Settling Time:25µs (V), 40µs (A) (Typ)
- Output Type:Voltage or Current - Buffered
- Differential Output:No
- Data Interface:SPI, DSP
- Reference Type:External, Internal
- Voltage - Supply, Analog:10.8V ~ 40V, -3V ~ 26.4V
- Voltage - Supply, Digital:2.7V ~ 5.5V
- INL/DNL (LSB):-, ±1.3 (Max)
- Architecture:R-2R
- Operating Temperature:-40°C ~ 105°C
- Package / Case:40-VFQFN Exposed Pad, CSP
- Supplier Device Package:40-LFCSP-VQ (6x6)
- Mounting Type:Surface Mount
