AD5760ACPZ-REEL7
Linear Technology (Analog Devices, Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC DAC 16BIT V-OUT 24LFCSP
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet AD5760ACPZ-REEL7 Datasheet
-
ECAD Model
- Share
In Stock: 133
Can ship immediately
Pricing:
- 1$13.3931
- 1,500$13.3931
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Active
- Number of Bits:16
- Number of D/A Converters:1
- Settling Time:3.5µs (Typ)
- Output Type:Voltage - Unbuffered
- Differential Output:No
- Data Interface:SPI, DSP
- Reference Type:External
- Voltage - Supply, Analog:7.5V ~ 16.5V, -2.5V ~ 16.5V
- Voltage - Supply, Digital:2.7V ~ 5.5V
- INL/DNL (LSB):±2 (Max), ±1 (Max)
- Architecture:R-2R
- Operating Temperature:-40°C ~ 125°C
- Package / Case:24-VFQFN Exposed Pad, CSP
- Supplier Device Package:24-LFCSP-VQ (4x5)
- Mounting Type:Surface Mount
