5051104396
Woodhead - Molex- Lifecycle status Active
- RoHS RoHS Compliant
- Description0.5 FPC ZIF BTM CONT EMBT PKG 43
- CategoryFFC, FPC (Flat Flexible) Connectors
-
ECAD Model
- Share
In Stock: 191
Can ship immediately
Pricing:
- 1$0.86695
Quote It
Technical Details
- Series:Easy-On FD19 505110
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Flat Flex Type:FFC, FPC
- Mounting Type:Surface Mount, Right Angle
- Connector/Contact Type:Contacts, Bottom
- Number of Positions:43
- Pitch:0.020" (0.50mm)
- Termination:Solder
- FFC, FCB Thickness:0.30mm
- Height Above Board:0.075" (1.90mm)
- Locking Feature:Flip Lock
- Cable End Type:Straight, Tabbed
- Contact Material:Copper Alloy
- Contact Finish:Gold
- Housing Material:Liquid Crystal Polymer (LCP), Glass Filled
- Actuator Material:Polyamide (PA), Nylon, Glass Filled
- Features:Solder Retention, Zero Insertion Force (ZIF)
- Voltage Rating:50V
- Operating Temperature:-40°C ~ 150°C
- Material Flammability Rating:UL94 V-0
