XF2M-2215-1A-R100
Omron Electronics Components
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN FPC 22POS 0.50MM R/A
- CategoryFFC, FPC (Flat Flexible) Connectors
- Datasheet XF2M-2215-1A-R100 Datasheet
-
ECAD Model
- Share
In Stock: 148
Can ship immediately
Pricing:
- 1$2.5726
- 100$2.3153
- 300$2.02593
- 500$1.96804
- 1,000$1.67862
- 2,500$1.67219
Quote It
Technical Details
- Series:XF2M
- Package:Tape & Reel (TR)
- Part Status:Active
- Flat Flex Type:FPC
- Mounting Type:Surface Mount, Right Angle
- Connector/Contact Type:Contacts, Top and Bottom
- Number of Positions:22
- Pitch:0.020" (0.50mm)
- Termination:Solder
- FFC, FCB Thickness:0.30mm
- Height Above Board:0.083" (2.10mm)
- Locking Feature:Rotary Lock, Backlock
- Cable End Type:Tapered
- Contact Material:Copper Alloy
- Contact Finish:Gold
- Housing Material:Liquid Crystal Polymer (LCP), Halogen Free
- Actuator Material:Liquid Crystal Polymer (LCP), Halogen Free
- Features:-
- Voltage Rating:50V
- Operating Temperature:-30°C ~ 85°C
- Material Flammability Rating:UL94 V-0
