SDI120-19-U2-P51
CUI Inc.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionAC/DC DESKTOP ADAPTER 19V 120W
- CategoryAC DC Desktop, Wall Adapters
- Datasheet SDI120-19-U2-P51 Datasheet
-
ECAD Model
- Share
In Stock: 114
Can ship immediately
Pricing:
- 1$57.16338
- 504$56.6979
Quote It
Technical Details
- Series:SDI120-U (120W)
- Package:Box
- Part Status:Active
- Region Utilized:Europe
- Form:Desktop (Class I)
- Input Type:Cord
- Voltage - Input:90 ~ 264 VAC
- Voltage - Output:19V
- Current - Output (Max):6.3A
- Power (Watts):120 W
- No Load Power Consumption:210mW (Max)
- Polarization:-
- Applications:ITE (Commercial)
- Efficiency:Level VI
- Operating Temperature:0°C ~ 40°C
- Output Connector:Power DIN, 4 Pin
- Cord Length:59" (1.50m)
- Input Connector:IEC 320-C14
- Size / Dimension:6.62" L x 2.60" W x 1.54" H (168.1mm x 66.0mm x 39.0mm)
- Approval Agency:CB Scheme, CCC, CSA, EN, FCC, IEC, PSE, RCM, UL
- Standard Number:C22.2 No. 60950-1; 55024; 55032 Class B; 60950-1; 61000-3-2; 61000-3-3; 62368-1
