SN74HCS03QDRQ1

Texas Instruments
  • Lifecycle status Active
  • RoHS RoHS Compliant
  • DescriptionIC GATE NAND 4CH 2-INP 14SOIC
  • CategoryLogic - Gates and Inverters
  • ECAD Model
  • Share
In Stock: 5,134

Can ship immediately

Pricing:
  • 1$0.38

Quote It

Technical Details

  • Series:Automotive, AEC-Q100, 74HCS
  • Package:Tape & Reel (TR)Cut Tape (CT)
  • Part Status:Active
  • Logic Type:NAND Gate
  • Number of Circuits:4
  • Number of Inputs:2
  • Features:Schmitt Trigger, Open Drain
  • Voltage - Supply:2V ~ 6V
  • Current - Quiescent (Max):2 µA



  • Current - Output High, Low:-, 7.8mA
  • Logic Level - Low:1V ~ 3V
  • Logic Level - High:1.5V ~ 4.2V
  • Max Propagation Delay @ V, Max CL:12ns @ 6V, 50pF
  • Operating Temperature:-40°C ~ 125°C
  • Mounting Type:Surface Mount
  • Supplier Device Package:14-SOIC
  • Package / Case:14-SOIC (0.154", 3.90mm Width)
