74AUP2G38GD,125
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE NAND OD 2CH 2-INP 8XSON
- CategoryLogic - Gates and Inverters
- Datasheet 74AUP2G38GD,125 Datasheet
-
ECAD Model
- Share
In Stock: 62,888
Can ship immediately
Pricing:
- 1$0.14
Quote It
Technical Details
- Series:74AUP
- Package:Bulk
- Part Status:Active
- Logic Type:NAND Gate
- Number of Circuits:2
- Number of Inputs:2
- Features:Open Drain
- Voltage - Supply:0.8V ~ 3.6V
- Current - Quiescent (Max):500 nA
- Current - Output High, Low:-, 4mA
- Logic Level - Low:0.7V ~ 0.9V
- Logic Level - High:1.6V ~ 2V
- Max Propagation Delay @ V, Max CL:12.7ns @ 3.3V, 30pF
- Operating Temperature:-40°C ~ 125°C
- Mounting Type:Surface Mount
- Supplier Device Package:8-XSON (2x3)
- Package / Case:8-XFDFN
