SN74AHC86NSR
Texas Instruments
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE XOR 4CH 2-INP 14SOP
- CategoryLogic - Gates and Inverters
-
ECAD Model
- Share
In Stock: 8,043
Can ship immediately
Pricing:
- 1$0.42
- 4,000$0.14105
Quote It
Technical Details
- Series:74AHC
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Logic Type:XOR (Exclusive OR)
- Number of Circuits:4
- Number of Inputs:2
- Features:-
- Voltage - Supply:2V ~ 5.5V
- Current - Quiescent (Max):2 µA
- Current - Output High, Low:8mA, 8mA
- Logic Level - Low:0.5V ~ 1.65V
- Logic Level - High:1.5V ~ 3.85V
- Max Propagation Delay @ V, Max CL:8.8ns @ 5V, 50pF
- Operating Temperature:-40°C ~ 125°C
- Mounting Type:Surface Mount
- Supplier Device Package:14-SOP
- Package / Case:14-SOIC (0.209", 5.30mm Width)
