MC74HC32ANG
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE OR 4CH 2-INP 14DIP
- CategoryLogic - Gates and Inverters
- Datasheet MC74HC32ANG Datasheet
-
ECAD Model
- Share
In Stock: 15,733
Can ship immediately
Pricing:
- 1$0.2
Quote It
Technical Details
- Series:74HC
- Package:Tube
- Part Status:Obsolete
- Logic Type:OR Gate
- Number of Circuits:4
- Number of Inputs:2
- Features:-
- Voltage - Supply:2V ~ 6V
- Current - Quiescent (Max):1 µA
- Current - Output High, Low:5.2mA, 5.2mA
- Logic Level - Low:0.5V ~ 1.8V
- Logic Level - High:1.5V ~ 4.2V
- Max Propagation Delay @ V, Max CL:13ns @ 6V, 50pF
- Operating Temperature:-55°C ~ 125°C
- Mounting Type:Through Hole
- Supplier Device Package:14-PDIP
- Package / Case:14-DIP (0.300", 7.62mm)
