• Lifecycle status Active
  • RoHS RoHS Compliant
  • DescriptionIC GATE XOR 4CH 2-INP 14DIP
  • CategoryLogic - Gates and Inverters
  • ECAD Model
  • Share
In Stock: 28,894

Can ship immediately

Pricing:
  • 1$1.41

Quote It

Technical Details

  • Series:74S
  • Package:Tube
  • Part Status:Obsolete
  • Logic Type:XOR (Exclusive OR)
  • Number of Circuits:4
  • Number of Inputs:2
  • Features:-
  • Voltage - Supply:4.75V ~ 5.25V
  • Current - Quiescent (Max):-



  • Current - Output High, Low:1mA, 20mA
  • Logic Level - Low:0.8V
  • Logic Level - High:2V
  • Max Propagation Delay @ V, Max CL:10.5ns @ 5V, 15pF
  • Operating Temperature:0°C ~ 70°C
  • Mounting Type:Through Hole
  • Supplier Device Package:14-PDIP
  • Package / Case:14-DIP (0.300", 7.62mm)
