SN74LS38DR
Texas Instruments
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE NAND OPEN 4CH 2IN 14SOIC
- CategoryLogic - Gates and Inverters
-
ECAD Model
- Share
In Stock: 1,799
Can ship immediately
Pricing:
- 1$0.99
- 2,500$0.3596
- 5,000$0.3348
- 12,500$0.3224
Quote It
Technical Details
- Series:74LS
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Logic Type:NAND Gate
- Number of Circuits:4
- Number of Inputs:2
- Features:Open Collector
- Voltage - Supply:4.75V ~ 5.25V
- Current - Quiescent (Max):2 mA
- Current - Output High, Low:-, 24mA
- Logic Level - Low:0.8V
- Logic Level - High:2V
- Max Propagation Delay @ V, Max CL:32ns @ 5V, 45pF
- Operating Temperature:0°C ~ 70°C
- Mounting Type:Surface Mount
- Supplier Device Package:14-SOIC
- Package / Case:14-SOIC (0.154", 3.90mm Width)
