SN74HCT14NE4

Texas Instruments
  • Lifecycle status Active
  • RoHS RoHS Compliant
  • DescriptionIC INVERT SCHMITT 6CH 6-IN 14DIP
  • CategoryLogic - Gates and Inverters
  • ECAD Model
  • Share
In Stock: 647

Can ship immediately

Pricing:
  • 1$0.65
  • 10$0.5525
  • 25$0.51582
  • 100$0.41275
  • 500$0.32431
  • 1,000$0.2506
  • 2,500$0.22849
  • 5,000$0.21374

Quote It

Technical Details

  • Series:74HCT
  • Package:Tube
  • Part Status:Active
  • Logic Type:Inverter
  • Number of Circuits:6
  • Number of Inputs:6
  • Features:Schmitt Trigger
  • Voltage - Supply:4.5V ~ 5.5V
  • Current - Quiescent (Max):2 µA



  • Current - Output High, Low:4mA, 4mA
  • Logic Level - Low:0.5V ~ 0.6V
  • Logic Level - High:1.9V ~ 2.1V
  • Max Propagation Delay @ V, Max CL:30ns @ 5.5V, 50pF
  • Operating Temperature:-40°C ~ 85°C
  • Mounting Type:Through Hole
  • Supplier Device Package:14-PDIP
  • Package / Case:14-DIP (0.300", 7.62mm)
