L50QS600.X
Wickmann / Littelfuse
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFUSE CRTRDGE 600A 500VAC/VDC
- CategoryElectrical, Specialty Fuses
- Datasheet L50QS600.X Datasheet
-
ECAD Model
- Share
In Stock: 109
Can ship immediately
Pricing:
- 1$132.16
Quote It
Technical Details
- Series:POWR-SPEED™ L50QS
- Package:-
- Part Status:Active
- Mounting Type:Bolt Mount
- Fuse Type:Cartridge
- Current Rating (Amps):600A
- Voltage Rating - AC:500 V
- Voltage Rating - DC:500 V
- Response Time:Fast Blow
- Applications:Semiconductors
- Features:-
- Class:-
- Approval Agency:CE, cURus, UR
- Operating Temperature:-55°C ~ 125°C
- Breaking Capacity @ Rated Voltage:200kA AC, 50kA DC
- Package / Case:Cylindrical, Blade Terminal (Bolt)
- Size / Dimension:2.000" Dia x 4.468" L (50.80mm x 113.49mm)
