2SC5242-O(Q)
Toshiba Electronic Devices and Storage Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTRANS NPN 230V 15A TO-3PN
- CategoryTransistors - Bipolar (BJT) - Single
- Datasheet 2SC5242-O(Q) Datasheet
-
ECAD Model
- Share
In Stock: 162
Can ship immediately
Pricing:
- 1$3.01
- 10$2.72246
- 50$2.43089
- 100$2.18788
- 250$1.94479
- 500$1.70168
- 1,000$1.40996
- 2,500$1.31272
- 5,000$1.29651
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Transistor Type:NPN
- Current - Collector (Ic) (Max):15 A
- Voltage - Collector Emitter Breakdown (Max):230 V
- Vce Saturation (Max) @ Ib, Ic:3V @ 800mA, 8A
- Current - Collector Cutoff (Max):5µA (ICBO)
- DC Current Gain (hFE) (Min) @ Ic, Vce:80 @ 1A, 5V
- Power - Max:130 W
- Frequency - Transition:30MHz
- Operating Temperature:150°C (TJ)
- Mounting Type:Through Hole
- Package / Case:TO-3P-3, SC-65-3
- Supplier Device Package:TO-3P(N)
