LT-2561-701-012
Carling Technologies
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSWITCH TOGGLE DPDT 15A 125V
- CategoryToggle Switches
- Datasheet LT-2561-701-012 Datasheet
-
ECAD Model
- Share
In Stock: 148
Can ship immediately
Pricing:
- 1$20.141
- 10$19.9996
Quote It
Technical Details
- Series:LT
- Package:Bulk
- Part Status:Active
- Mounting Type:Panel Mount
- Circuit:DPDT
- Switch Function:On-Off-On
- Current Rating (Amps):15A (AC/DC)
- Voltage Rating - AC:125 V
- Voltage Rating - DC:28 V
- Actuator Type:Standard Round
- Actuator Length:18.16mm
- Illumination:Illuminated
- Illumination Type, Color:Incandescent, Red
- Illumination Voltage (Nominal):12 VAC
- Termination Style:Quick Connect - 0.250" (6.3mm)
- Panel Cutout Dimensions:Circular - 12.70mm Dia
- Bushing Thread:15/32-32
- Ingress Protection:-
- Features:Sealed
- Operating Temperature:0°C ~ 85°C
