AP1538SG-13
Zetex Semiconductors (Diodes Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC REG BUCK ADJUSTABLE 3A 8SOP
- CategoryPMIC - Voltage Regulators - DC DC Switching Regulators
- Datasheet AP1538SG-13 Datasheet
-
ECAD Model
- Share
In Stock: 163
Can ship immediately
Pricing:
- 1$0.39375
- 2,500$0.39375
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Active
- Function:Step-Down
- Output Configuration:Positive
- Topology:Buck
- Output Type:Adjustable
- Number of Outputs:1
- Voltage - Input (Min):3.6V
- Voltage - Input (Max):18V
- Voltage - Output (Min/Fixed):0.8V
- Voltage - Output (Max):18V
- Current - Output:3A
- Frequency - Switching:300kHz
- Synchronous Rectifier:No
- Operating Temperature:-20°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Package / Case:8-SOIC (0.154", 3.90mm Width)
- Supplier Device Package:8-SOP
