MP2209DL-LF-Z
MPS (Monolithic Power Systems)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC REG BUCK ADJUSTABLE 2A 14QFN
- CategoryPMIC - Voltage Regulators - DC DC Switching Regulators
- Datasheet MP2209DL-LF-Z Datasheet
-
ECAD Model
- Share
In Stock: 5,131
Can ship immediately
Pricing:
- 1$1.932
- 5,000$1.932
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Not For New Designs
- Function:Step-Down
- Output Configuration:Positive
- Topology:Buck
- Output Type:Adjustable
- Number of Outputs:1
- Voltage - Input (Min):3V
- Voltage - Input (Max):16V
- Voltage - Output (Min/Fixed):0.8V
- Voltage - Output (Max):14.4V
- Current - Output:2A
- Frequency - Switching:600kHz
- Synchronous Rectifier:Yes
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Package / Case:14-VFDFN Exposed Pad
- Supplier Device Package:14-QFN (3x4)
