RJK0368DPA-00#J0

Technical Details

• Series:-
• Package:Bulk
• Part Status:Obsolete
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):30 V
• Current - Continuous Drain (Id) @ 25°C:20A (Ta)
• Drive Voltage (Max Rds On, Min Rds On):-
• Rds On (Max) @ Id, Vgs:14.3mOhm @ 10A, 10V
• Vgs(th) (Max) @ Id:2.5V @ 1mA

• Gate Charge (Qg) (Max) @ Vgs:6.2 nC @ 4.5 V
• Vgs (Max):-
• Input Capacitance (Ciss) (Max) @ Vds:730 pF @ 10 V
• FET Feature:-
• Power Dissipation (Max):25W (Tc)
• Operating Temperature:150°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:8-WPAK
• Package / Case:8-PowerWDFN
