SSM3J140TU,LF
Toshiba Electronic Devices and Storage Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET P-CH 20V 4.4A UFM
- CategoryTransistors - FETs, MOSFETs - Single
-
ECAD Model
- Share
In Stock: 2,551
Can ship immediately
Pricing:
- 1$0.5
- 3,000$0.1663
- 6,000$0.15557
- 15,000$0.15021
Quote It
Technical Details
- Series:U-MOSVI
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- FET Type:P-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):20 V
- Current - Continuous Drain (Id) @ 25°C:4.4A (Ta)
- Drive Voltage (Max Rds On, Min Rds On):1.5V, 4.5V
- Rds On (Max) @ Id, Vgs:25.8mOhm @ 4A, 4.5V
- Vgs(th) (Max) @ Id:1V @ 1mA
- Gate Charge (Qg) (Max) @ Vgs:24.8 nC @ 4.5 V
- Vgs (Max):+6V, -8V
- Input Capacitance (Ciss) (Max) @ Vds:1800 pF @ 10 V
- FET Feature:-
- Power Dissipation (Max):500mW (Ta)
- Operating Temperature:150°C
- Mounting Type:Surface Mount
- Supplier Device Package:UFM
- Package / Case:3-SMD, Flat Lead
