TSM70N750CH C5G
TSC (Taiwan Semiconductor)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CHANNEL 700V 6A TO251
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet TSM70N750CH C5G Datasheet
-
ECAD Model
- Share
In Stock: 1,909
Can ship immediately
Pricing:
- 1$2.39
- 10$2.11595
- 100$1.67188
- 500$1.29662
- 1,875$1.02363
- 3,750$0.95539
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):700 V
- Current - Continuous Drain (Id) @ 25°C:6A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:750mOhm @ 1.8A, 10V
- Vgs(th) (Max) @ Id:4V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:10.7 nC @ 10 V
- Vgs (Max):±30V
- Input Capacitance (Ciss) (Max) @ Vds:555 pF @ 100 V
- FET Feature:-
- Power Dissipation (Max):62.5W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Through Hole
- Supplier Device Package:TO-251 (IPAK)
- Package / Case:TO-251-3 Short Leads, IPak, TO-251AA
