FDB9403-F085
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 40V 110A TO263AB
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet FDB9403-F085 Datasheet
-
ECAD Model
- Share
In Stock: 1,924,929
Can ship immediately
Pricing:
- 1$4.84
- 800$2.07396
- 1,600$1.9357
- 2,400$1.83891
- 5,600$1.76978
Quote It
Technical Details
- Series:Automotive, AEC-Q101, PowerTrench®
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):40 V
- Current - Continuous Drain (Id) @ 25°C:110A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:1.2mOhm @ 80A, 10V
- Vgs(th) (Max) @ Id:4V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:213 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:12700 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):333W (Tj)
- Operating Temperature:-55°C ~ 175°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:TO-263AB
- Package / Case:TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
