IPD50R1K4CEAUMA1
IR (Infineon Technologies)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 500V 3.1A TO252-3
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet IPD50R1K4CEAUMA1 Datasheet
-
ECAD Model
- Share
In Stock: 2,587
Can ship immediately
Pricing:
- 1$0.54
- 2,500$0.19866
Quote It
Technical Details
- Series:CoolMOS™ CE
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):500 V
- Current - Continuous Drain (Id) @ 25°C:3.1A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):13V
- Rds On (Max) @ Id, Vgs:1.4Ohm @ 900mA, 13V
- Vgs(th) (Max) @ Id:3.5V @ 70µA
- Gate Charge (Qg) (Max) @ Vgs:8.2 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:178 pF @ 100 V
- FET Feature:-
- Power Dissipation (Max):42W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:PG-TO252-3
- Package / Case:TO-252-3, DPak (2 Leads + Tab), SC-63
