CSD18502Q5BT

Texas Instruments
In Stock: 618

Can ship immediately

Pricing:
  • 1$2.88
  • 250$1.68433
  • 500$1.47379
  • 750$1.33062
  • 1,250$1.22114

Quote It

Technical Details

  • Series:NexFET™
  • Package:Tape & Reel (TR)Cut Tape (CT)
  • Part Status:Active
  • FET Type:N-Channel
  • Technology:MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss):40 V
  • Current - Continuous Drain (Id) @ 25°C:100A (Ta)
  • Drive Voltage (Max Rds On, Min Rds On):4.5V, 10V
  • Rds On (Max) @ Id, Vgs:2.3mOhm @ 30A, 10V
  • Vgs(th) (Max) @ Id:2.2V @ 250µA



  • Gate Charge (Qg) (Max) @ Vgs:33 nC @ 4.5 V
  • Vgs (Max):±20V
  • Input Capacitance (Ciss) (Max) @ Vds:5070 pF @ 20 V
  • FET Feature:-
  • Power Dissipation (Max):3.2W (Ta), 156W (Tc)
  • Operating Temperature:-55°C ~ 150°C (TJ)
  • Mounting Type:Surface Mount
  • Supplier Device Package:8-VSON-CLIP (5x6)
  • Package / Case:8-PowerTDFN
