IXTY08N100P
Wickmann / Littelfuse
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 1000V 800MA TO252
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet IXTY08N100P Datasheet
-
ECAD Model
- Share
In Stock: 245,539
Can ship immediately
Pricing:
- 1$3.03
- 70$2.42058
Quote It
Technical Details
- Series:Polar™
- Package:Tube
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):1000 V
- Current - Continuous Drain (Id) @ 25°C:800mA (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:20Ohm @ 500mA, 10V
- Vgs(th) (Max) @ Id:4V @ 50µA
- Gate Charge (Qg) (Max) @ Vgs:11.3 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:240 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):42W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:TO-252, (D-Pak)
- Package / Case:TO-252-3, DPak (2 Leads + Tab), SC-63
