R5009FNJTL
ROHM Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 500V 9A LPTS
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet R5009FNJTL Datasheet
-
ECAD Model
- Share
In Stock: 1,153
Can ship immediately
Pricing:
- 1$2.18
- 1,000$1.01001
- 2,000$0.97519
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Not For New Designs
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):500 V
- Current - Continuous Drain (Id) @ 25°C:9A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:840mOhm @ 4.5A, 10V
- Vgs(th) (Max) @ Id:4V @ 1mA
- Gate Charge (Qg) (Max) @ Vgs:18 nC @ 10 V
- Vgs (Max):±30V
- Input Capacitance (Ciss) (Max) @ Vds:630 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):50W (Tc)
- Operating Temperature:150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:LPTS
- Package / Case:TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
