IRFH7110TRPBF

Technical Details

• Series:HEXFET®
• Package:Bulk
• Part Status:Obsolete
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):100 V
• Current - Continuous Drain (Id) @ 25°C:11A (Ta), 58A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):10V
• Rds On (Max) @ Id, Vgs:13.5mOhm @ 35A, 10V
• Vgs(th) (Max) @ Id:4V @ 100µA

• Gate Charge (Qg) (Max) @ Vgs:87 nC @ 10 V
• Vgs (Max):±20V
• Input Capacitance (Ciss) (Max) @ Vds:3.24 pF @ 25 V
• FET Feature:-
• Power Dissipation (Max):3.6W (Ta), 104W (Tc)
• Operating Temperature:-55°C ~ 150°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:8-PQFN (5x6)
• Package / Case:8-TQFN Exposed Pad
